Pyxis HM-520 Inline Oil In Water Fluorometer (Mid Range)

Inline oil-in-water fluorometer, mid range (0-100ppm). 4-20mA + RS-485, 7-pin.

Pyxis Lab
Fluorometric Sensor
Water Treatment

Pyxis HM-520 Inline Oil In Water Fluorometer (Mid Range)

Model:
HM-520
Brand:
Pyxis Lab

The Pyxis HM-520 is an inline oil-in-water fluorometer for produced water, wastewater discharge compliance, and process water monitoring. This mid-range variant covers 0-100ppm and outputs via both 4-20mA analog and RS-485 Modbus through a single 7-pin connector, bridging standard and high-range monitoring needs.

Mid-range compliance monitoring — covers 0-100ppm for applications between standard and high-range oil-in-water levels
Dual output design — 4-20mA analog plus RS-485 Modbus supports both analog controllers and networked SCADA systems
Mid-range compliance monitoring — covers 0-100ppm for applications between standard and high-range oil-in-water levels

Description

The Pyxis HM-520 is a mid-range inline oil-in-water fluorometer for produced water, wastewater discharge compliance, and process water monitoring, covering a 0-100ppm range using fluorometric detection. It bridges the gap between the standard-range HM-500 and the high-range HM-510, giving operators an option matched to intermediate oil-in-water concentrations.

The HM-520 outputs via both 4-20mA analog and RS-485 Modbus communication, delivered through a single 7-pin connector, so it integrates with either analog control loops or networked PLC/SCADA systems.

It suits process streams where oil-in-water levels are too high for a low-range instrument but don’t require the HM-510’s full high-range coverage.

Why Use This

Monitoring at Mid-Range Concentrations

Covering 0-100ppm, the HM-520 fits oil-in-water monitoring applications that fall between standard low-range and high-range sensor coverage.

Flexible System Integration

4-20mA analog output combined with RS-485 Modbus lets the sensor communicate with both analog controllers and networked control systems through one 7-pin connector.

Applications

  • Mid-range produced water monitoring
  • Wastewater discharge compliance monitoring for intermediate oil concentrations
  • Process water monitoring bridging standard and high-range needs

FAQ

What range does the HM-520 cover?

It covers a mid-range of 0-100ppm oil-in-water concentration using fluorometric detection.

How does it compare to the HM-500 and HM-510?

The HM-520 bridges the standard-range HM-500 (0-10ppm) and the high-range HM-510 (0-1,000ppm), suiting intermediate oil-in-water concentrations.

What applications is it designed for?

Produced water monitoring, wastewater discharge compliance, and process water monitoring.

What outputs does the sensor provide?

4-20mA analog and RS-485 Modbus outputs, delivered through a single 7-pin connector.
