The Fluimac Phoenix P35 is an air-operated double diaphragm (AODD) pump rated for 35 lt/min maximum flow, available in multiple casing materials to suit different chemical compatibility and application requirements. The pump uses a seal-less, valve-ball design capable of dry-running without damage, self-priming to 5 m of dry suction lift, and safe deadheading against closed discharge without pump damage.

Each material variant is available with a range of diaphragm, ball, seat, and gasket material combinations to match specific chemical compatibility needs — consult Autoflo for the correct composition code for your application.

Key specifications:

• Fluid connections: 1/2″ BSPP
• Air connection: 1/4″ BSPP
• Max flow rate: 35 lt/min
• Max air pressure: 7 bar
• Max delivery head: 70 m
• Max suction lift (dry): 5 m
• Max suction lift (wet): 9.8 m
• Max solid passing: 3 mm
• Noise level: 65 dB
• Max viscosity: 15,000 cps
• Displacement per stroke: ~65 cc
• ATEX: II 3/3 G Ex h IIC T4 Gc / II 3 D Ex h IIIB T135°C Dc X
