Dosatron D90GL05BP MEGAFLOW Fertigation Dosing Pump
Mega-flow water-powered fertigation pump for very high volume irrigation networks, up to 90 m3/h.
Dosatron D90GL05BP MEGAFLOW Fertigation Dosing Pump
The D90GL05BP MEGAFLOW extends Dosatron's Green Line to very high flow rate dosing, up to 90 m3/h, with no electricity or additional energy required beyond the water flow itself. It is designed to manage network filling phases and restart automatically after supply overflow, suited to field crop irrigation, vegetable production and orchards.
Description
The Dosatron D90GL05BP MEGAFLOW extends Dosatron’s Green Line to very high flow rate dosing, up to 90 m3/h, with no electricity or additional energy required beyond the water flow itself. It is designed to manage network filling phases and restart automatically after supply overflow.
It offers an injection range of 0.1-0.5% (1:1000 to 1:200) across a water flow range of 25-90 m3/h and operating pressure of 0.5-8 bar, with concentrated additive injection of 25-450 l/h and DN 100 DIN ASME flange connections sized for high-flow network piping.
It suits field crop irrigation (drip, pivots, reel machines), vegetable production and orchards. Recommended installation is a full hydraulic bypass with an upstream filter to protect the mechanism and extend service life.
Why Use This
Handles very high irrigation volumes
Scales up to 90 m3/h with no electricity or additional energy source, suited to drip, pivot and reel machine irrigation, vegetable production and orchards.
Manages network filling automatically
Restarts automatically after supply overflow, reducing manual intervention during network filling phases.
Protect with proper installation
A full hydraulic bypass with an upstream filter is recommended to protect the mechanism and extend service life.
Applications
- Field crop irrigation — drip systems, pivots and reel machines at very high flow rates
- Vegetable production and orchards requiring large-scale fertigation dosing
- High-volume networks up to 90 m3/h needing automatic restart after overflow
FAQ
What flow rate can the D90GL05BP MEGAFLOW handle?
It manages very high flow rate dosing up to 90 m3/h, with no electricity or additional energy required beyond the water flow itself.
What happens if the water supply overflows or the network is filling?
It is designed to manage network filling phases and restart automatically after supply overflow.
What installation is recommended for the MEGAFLOW?
A full hydraulic bypass with an upstream filter is recommended to protect the mechanism and extend service life.
What irrigation systems is it suited to?
It suits field crop irrigation (drip, pivots, reel machines), vegetable production and orchards.
