Pyxis SP-710 Handheld Water Multimeter
Handheld multimeter measuring pH (0-14), ORP (±1,500mV), Conductivity (0-15,000uS/cm), PTSA (0-300ppb), and Free & Total Chlorine (TMB), suited to boiler applications.
Pyxis SP-710 Handheld Water Multimeter
The Pyxis SP-710 is a handheld multimeter that measures up to six key water treatment parameters simultaneously — pH, Conductivity, PTSA, Temperature, ORP, and Fluorescein — making it well suited to boiler water applications. A fully potted, Bluetooth-enabled pH/ORP module eliminates water and KCl contamination risks, while combined electrochemical and optical measurement delivers fluorescence precision to within ±1ppb.
Description
The Pyxis SP-710 is a handheld multimeter that measures up to six key water treatment parameters simultaneously — pH, Conductivity, PTSA, Temperature, ORP, and Fluorescein — making it well suited to boiler water applications where tracer-based dosing control is common.
A fully potted, Bluetooth-enabled, battery-powered pH/ORP module eliminates water and KCl contamination risks and communicates wirelessly with the base unit, viewable via the uPyxis app. A fully moulded, water-proof screen and integrated humidity sensor support reliable field use, and measurement history — including calendar time marks and sample location — transfers via Bluetooth to smartphones or computers.
One-handed operation combines electrochemical and optical measurement in a cuvette-less platform, with simultaneous colour and turbidity compensation during fluorescence testing for precision to ±1ppb. The SP-710 also supports wireless diagnosis and calibration of the Pyxis Lab ST-500 sensor, and an optional carrying case (MA-700) is available for field transport in industrial and commercial cooling tower and boiler applications.
Why Use This
Complete Boiler Water Picture
Measuring six key parameters in one meter gives boiler water operators a fast, complete field snapshot without switching between instruments.
Protected, Precise Measurement
A fully potted pH/ORP module prevents contamination damage, while colour and turbidity compensation keep fluorescence readings precise to ±1ppb.
Applications
- Industrial and commercial boilers — six-parameter monitoring including PTSA tracer dosing control
- Cooling tower water treatment — combined pH, conductivity, ORP, and fluorescence checks
FAQ
What parameters does the SP-710 measure?
It measures up to six parameters simultaneously: pH, Conductivity, PTSA, Temperature, ORP, and Fluorescein.
How precise is the fluorescence (PTSA) measurement?
Colour and turbidity auto-compensation deliver fluorescence precision to ±1ppb, with a PTSA range of 0-300ppb.
Is the pH/ORP module field-replaceable?
Yes, it is fully potted, battery-powered, and Bluetooth-enabled, eliminating water and KCl contamination risks during replacement.
Does the SP-710 connect to other Pyxis Lab equipment?
Yes, it supports wireless diagnosis and calibration of the Pyxis Lab ST-500 sensor via the uPyxis app.
