Pyxis LT-739B Ultralow Turbidity Sensor (Infrared Light, Mid Range)
Ultra-low turbidity sensor, infrared light 860nm, 0.000-40.000NTU, 0.002NTU resolution, 2% accuracy, ISO 7027. Dual 4-20mA + RS-485, 8-pin.
Pyxis LT-739B Ultralow Turbidity Sensor (Infrared Light, Mid Range)
The Pyxis LT-739B is a mid-range ultralow turbidity sensor using infrared light (860nm) illumination, built for resolution and accuracy beyond a standard process turbidimeter. It measures 0.000-40.000NTU with 0.002NTU resolution and 2% accuracy to ISO 7027, with dual 4-20mA analog outputs plus RS-485 through an 8-pin connector.
Description
The Pyxis LT-739B is the mid-range, infrared-light (860nm) variant of the ultralow turbidity sensor family, delivering resolution and accuracy beyond a standard process turbidimeter. It measures across a 0.000-40.000NTU range with 0.002NTU resolution and 2% accuracy, tested to the ISO 7027 method.
It communicates through dual 4-20mA analog outputs plus RS-485 via an 8-pin connector, integrating with existing control and monitoring systems.
The mid-range span and ISO 7027 referencing make it a fit for process applications in the tens-of-NTU window where that standard, rather than EPA 180.1, applies.
Why Use This
Balanced Range and Precision
Covers 0.000-40.000NTU with 0.002NTU resolution and 2% accuracy to ISO 7027, suited to mid-range low-turbidity monitoring.
Flexible Signal Output
Dual 4-20mA analog outputs plus RS-485 via an 8-pin connector support integration into existing systems.
Applications
- Mid-range process turbidity monitoring — tailored to the 0-40NTU window under ISO 7027
- Regional compliance monitoring — where ISO 7027 is the applicable standard
- Treated water clarity verification — precision beyond standard process turbidimeters
FAQ
What range does the LT-739B cover?
0.000-40.000NTU, with 0.002NTU resolution and 2% accuracy.
What standard is it measured to, and how does that affect the design?
ISO 7027, using infrared (860nm) light illumination — the infrared counterpart to the warm-white-light LT-739, which is measured to EPA 180.1.
What outputs does it provide?
Dual 4-20mA analog outputs plus RS-485, via an 8-pin connector.
Is this suited to process control or low-range compliance monitoring?
Its mid-range span (0-40NTU) suits process turbidity monitoring in that window, positioned between the low-range LT-737B and the broader-range LT-736B.
