Pyxis HM-510 Inline Oil In Water Fluorometer (High Range)

Inline oil-in-water fluorometer, high range (0-1,000ppm). 4-20mA + RS-485, 7-pin.

Pyxis Lab
Fluorometric Sensor
Water Treatment

Pyxis HM-510 Inline Oil In Water Fluorometer (High Range)

Model:
HM-510
Brand:
Pyxis Lab

The Pyxis HM-510 is an inline oil-in-water fluorometer for produced water, wastewater discharge compliance, and process water monitoring. This high-range variant covers 0-1,000ppm and outputs via both 4-20mA analog and RS-485 Modbus through a single 7-pin connector, suiting applications with higher oil-in-water concentrations.

High-range compliance monitoring — covers 0-1,000ppm for applications with elevated oil-in-water concentrations
Dual output design — 4-20mA analog plus RS-485 Modbus supports both analog controllers and networked SCADA systems
High-range compliance monitoring — covers 0-1,000ppm for applications with elevated oil-in-water concentrations

Description

The Pyxis HM-510 is a high-range inline oil-in-water fluorometer built for produced water, wastewater discharge compliance, and process water monitoring applications where oil concentrations run higher than standard-range instruments can track. It covers 0-1,000ppm using fluorometric detection.

Like other instruments in the Pyxis inline sensor line, the HM-510 outputs via both 4-20mA analog and RS-485 Modbus communication, delivered through a single 7-pin connector for simplified wiring and installation.

This high-range capability makes the HM-510 a fit for process streams with elevated oil-in-water content, giving operators continuous inline visibility where lower-range instruments would be overwhelmed.

Why Use This

Monitoring at Higher Oil Concentrations

The 0-1,000ppm high-range span lets the HM-510 track oil-in-water levels in streams where concentrations exceed standard low-range sensor limits.

Flexible System Integration

4-20mA analog output combined with RS-485 Modbus lets the sensor communicate with both analog controllers and networked control systems through one 7-pin connector.

Applications

  • Produced water monitoring with elevated oil content
  • Wastewater discharge compliance monitoring in high-concentration streams
  • Process water monitoring where oil levels exceed standard-range instrument capability

FAQ

What range of oil-in-water concentration does the HM-510 measure?

It covers a high range of 0-1,000ppm using fluorometric detection.

What is this instrument used for?

It is intended for produced water, wastewater discharge compliance, and process water monitoring applications with elevated oil-in-water concentrations.

What outputs and connections does it use?

It outputs via both 4-20mA analog and RS-485 Modbus, through a single 7-pin connector.

How is this different from the standard HM-500?

The HM-510 is the high-range variant, covering 0-1,000ppm versus the HM-500’s 0-10ppm, for applications with higher oil-in-water concentrations.
